Check valve fitting

• Areas of aplication : compressed air, filtered, lubrificated
• Technical features
  - body in nickel plated brass
  - spring in stainless steel AISI 302
  - oil-proof rubber packing NBR
  - maximum pressure : 10 bar
  - working temperature : 0°C ÷ 60°C

This fitting is provided with a check valve that opens when inserting the tubing into the fi tting, only then the air passage is allowed.
Should the tube accidentally get realeased, the valve would immediately close again and the air fl ow would stop.
